Brake Shoe Set:84Y5-26-38Z--Fujian Huari Automotive Parts Co., Ltd.

Beschreibung
Ref.:	84Y5-26-38Z
Huari No.:	HRK3373
Name:	Brake Shoe Set
Unit:	SET
Price:
Rear Axle Brake System : Sumitomo Diameter : 200 mm Width : 26 mm

Model	Engine			Type	CYL	year
MAZDA 323 C IV (BG)					8/89 - 7/94
323 C IV (BG) 1.3	B3E	1324	67	Hatchback	4	9/89 - 7/94
323 C IV (BG) 1.3 16V	B3 (16V)	1324	73	Hatchback	4	9/89 - 7/94
323 C IV (BG) 1.6	B6E	1598	84	Hatchback	4	9/89 - 6/91
323 C IV (BG) 1.7 D	PN54	1720	56	Hatchback	4	8/89 - 7/94
MAZDA 323 F IV (BG)					9/89 - 6/91
323 F IV (BG) 1.6	B6E	1598	84	Hatchback	4	9/89 - 6/91
MAZDA 323 S IV (BG)					8/89 - 7/94
323 S IV (BG) 1.3	B383	1324	67	Saloon	4	9/89 - 6/91
323 S IV (BG) 1.6	B6E	1598	84	Saloon	4	9/89 - 6/91
323 S IV (BG) 1.6 16V	B6	1598	88	Saloon	4	8/89 - 0/94
323 S IV (BG) 1.7 D	PN46	1720	56	Saloon	4	8/89 - 7/94

Anwendung

MAZDA LASER BG3PF 1300 (~NO.300280) 89' 4-90' 11
MAZDA LASER BG7PF 1700 (~NO.110172) 89' 4-90' 11
MAZDA LASER BG5PF 1500 (~NO.302498) 89' 4-90' 11
MAZDA EUNOS 100 BG5PE 1500 89' 11-93' 12
MAZDA FAMILIA BG5P 1500 89' 1-90' 1
MAZDA FAMILIA BG3S 1300 89' 1-90' 1
MAZDA FAMILIA BG3P 1300 89' 1-90' 1
MAZDA FAMILIA BG8Z 1800 89' 6-90' 11
MAZDA FAMILIA BG5S 1500 89' 11-90' 1
MAZDA FAMILIA BG7P 1700 89' 1-90' 1

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
