Brake Shoe Set:B5Y6-26-38Z--Fujian Huari Automotive Parts Co., Ltd.

Beschreibung
Ref.:	B5Y6-26-38Z
Huari No.:	HRK3385
Name:	Brake Shoe Set
Unit:	SET
Price:
Rear Axle Brake System : SUMITOMO Diameter : 200 mm Width : 36 mm

Model	Engine			Type	CYL	year
MAZDA 323 C IV (BG)					8/89 - 7/94
323 C IV (BG) 1.3 16V	B3 (16V)	1324	73	Hatchback	4	9/89 - 7/94
323 C IV (BG) 1.6 16V	B6	1598	88	Hatchback	4	3/91 - 0/94
323 C IV (BG) 1.7 D	PN54	1720	56	Hatchback	4	8/89 - 7/94
MAZDA 323 C V (BA)					8/94 - 9/98
323 C V (BA) 1.3 16V	B3 (16V)	1324	73	Coupe	4	8/94 - 9/98
323 C V (BA) 1.5 16V	Z5-DE	1489	88	Coupe	4	8/94 - 9/98
323 C V (BA) 1.8 16V	BP-ZE	1840	114	Coupe	4	8/94 - 9/98
MAZDA 323 F IV (BG)					3/91 - 0/94
323 F IV (BG) 1.6 16V	B6	1598	88	Hatchback	4	3/91 - 0/94
MAZDA 323 F V (BA)					8/94 - 9/98
323 F V (BA) 1.5 16V	Z5-DE	1489	88	Hatchback	4	7/94 - 9/98
323 F V (BA) 1.8 16V	BP-ZE	1840	114	Hatchback	4	8/94 - 9/98
MAZDA 323 F VI (BJ)					9/98 - 1/01
323 F VI (BJ) 2.0 D	RF1G	1998	71	Hatchback	4	9/98 - 5/04
323 F VI (BJ) 1.4 16V	B3 ME	1324	73	Hatchback	4	9/98 - 1/01
MAZDA 323 P V (BA)					10/96 - /
323 P V (BA) 2.0 D	RF1G	1998	71	Hatchback	4	0/96 - 9/98
323 P V (BA)1.3 16 V		1324	73	Hatchback		10/96 - /
323 P V (BA)1.5 16 V		1489	88	Hatchback		10/96 - /
MAZDA 323 S IV (BG)					8/89 - 7/94
323 S IV (BG) 1.3 16V	B3 (16V)	1324	73	Saloon	4	4/91 - 7/94
323 S IV (BG) 1.6 16V	B6	1598	88	Saloon	4	8/89 - 0/94
323 S IV (BG) 1.7 D	PN46	1720	56	Saloon	4	8/89 - 7/94
MAZDA 323 S V (BA)					0/96 - 9/98
323 S V (BA) 1.3 16V	B3 (16V)	1324	73	Saloon	4	8/94 - 9/98
323 S V (BA) 1.5 16V	Z5-DE	1489	88	Saloon	4	8/94 - 9/98
323 S V (BA) 1.6 TD	4EE1-T	1686	82	Saloon	4	5/94 - 9/98
323 S V (BA) 1.8 16V	BP-ZE	1840	114	Saloon	4	8/94 - 9/98
323 S V (BA) 2.0 D	RF1G	1998	71	Saloon	4	0/96 - 9/98
MAZDA 323 S VI (BJ)					9/98 - 5/04
323 S VI (BJ) 2.0 D	RF1G	1998	71	Saloon	4	9/98 - 5/04
MAZDA MX-3 (EC)					1/92 - 1/94
MX-3 (EC) 1.6 i	B69	1598	88	Coupe	4	7/91 - 0/97
MX-3 (EC) 1.6 i	B6D	1598	107	Coupe	4	1/94 - 0/97
MX-3 (EC) 1.8 i V6	K819	1845	133	Coupe	6	1/92 - 1/94

Anwendung

MAZDA LASER BHA5SF 1500 R 94' 6-
MAZDA LASER BHA7PF 1700 R 94' 6-
MAZDA LASER BG7PF 1700 (NO.110173~) 90' 11-
MAZDA LASER BG3PF 1300 (NO.300281~) 90' 11-
MAZDA LASER BHALSF 1500 R 94' 6-
MAZDA LASER BHALPF 1500 R 94' 6-
MAZDA LASER BG5PF 1500 (NO.302499~) 90' 11-
MAZDA AZ-3 EC5SA 1500 ABS 91' 6-98' 3
MAZDA FAMILIA BHA3P 1300 94' 6-98' 5
MAZDA FAMILIA BHA3S 1300 94' 6-98' 5
MAZDA FAMILIA BG3P 1300 (NO.300931~)R 90' 1-94' 6
MAZDA FAMILIA BG5P 1500 (NO.309862~)R 90' 1-94' 6
MAZDA FAMILIA BG3S 1300 (NO.3015541~)R 90' 1-94' 6
MAZDA FAMILIA BG7P 1700 (NO.130436~)R 90' 1-94' 6
MAZDA FAMILIA BHA7P 1700 R 94' 6-98' 12
MAZDA FAMILIA BHA8P 1800 R 94' 6-98' 12
MAZDA FAMILIA BG5S 1500 (NO.305031~)R 90' 1-94' 6
MAZDA FAMILIA BHALP 1500 R 94' 6-98' 12
MAZDA FAMILIA BHALS 1500 R 94' 6-98' 12
MAZDA FAMILIA BHA5P 1500 R 94' 6-96' 10
MAZDA FAMILIA BHA5S 1500 R 94' 6-96' 10
MAZDA FAMILIA BHA8S 1800 R 94' 6-98' 5

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
