Beschreibung
Ref.:	D6Y1-33-28Z
Huari No.:	HR1379
Name:	Brake Pad Set
Unit:	SET
Price:
Front Axle Width : 126 mm Height : 48.3 mm Thickness : 14.7 mm

Brake Pad Set:D6Y1-33-28Z

Model	Engine	Chassis			Type	CYL	year
MAZDA 2 (DE_, DH_3)						1/10 - 6/15
2 (DE_, DH_3) 1.3	ZJ-VE		1349	75	Hatchback	4	0/07 - 6/15
2 (DE_, DH_3) 1.3	ZJ-VE		1349	86	Hatchback	4	0/07 - 6/15
2 (DE_, DH_3) 1.5	ZY-VE		1498	103	Hatchback	4	0/07 - 6/15
2 (DE_, DH_3) 1.4 MZR-CD	Y404		1399	68	Hatchback	4	1/08 - 6/15
2 (DE_, DH_3) 1.6 MZ-CD	Y646		1560	90	Hatchback	4	0/08 - 6/15
2 (DE_, DH_3) 1.6 MZ-CD	Y655		1560	95	Hatchback	4	6/11 - 6/15
2 (DE_, DH_3) 1.5 MZR	ZY05		1498	102	Hatchback	4	6/11 - 6/15
2 (DE_, DH_3) 1.3 MZR	ZJ-VE		1349	84	Hatchback	4	1/10 - 6/15

Anwendung

MAZDA DEMIO 1500 DE5FS 2007/07-
DAIHATSU BOON 1000 M300S 2006/12-
DAIHATSU BOON 1300 M301S 2006/12-

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
