  • Description
     04466-05010
     HR1215
     Brake Pad Set
     SET

    Rear Axle
    Brake System : BOS
    Width : 102 mm
    Height : 46.1 mm
    Thickness : 16.3 mm

Brake Pad Set:04466-05010
Model Engine Chassis Type CYL year
TOYOTA ALPHARD / VELLFIRE (_H2_)  1/10 - 2/14
TOYOTA AVENSIS (_T22_)  0/00 - 2/03
TOYOTA AVENSIS (_T25_)  4/03 - 1/08
TOYOTA AVENSIS Estate (_T25_)  4/03 - 1/08
TOYOTA AVENSIS Liftback (_T22_)  0/00 - 2/03
TOYOTA AVENSIS Saloon (T25)  0/03 - 1/08
TOYOTA COROLLA Verso (ZER_, ZZE12_, R1_)  0/05 - 3/09
TOYOTA COROLLA Verso (_E12J_)  9/01 - 7/04
TOYOTA PREVIA (_R3_)  2/00 - 1/06
TOYOTA PREVIA III (_R2_, _R5_)  8/06 - /


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
