• Description
     190 6039
     HR1244
     Brake Pad Set
     SET

    Front Axle
    Brake System : BRB
    Width : 109.6 mm
    Height : 73 mm
    Thickness : 18.3 mm

Brake Pad Set:190 6039
Model Engine Chassis Type CYL year
IVECO DAILY I Box Body / Estate  0/90 - 4/96
IVECO DAILY I Platform/Chassis  0/90 - 4/96
IVECO DAILY II Box Body / Estate  1/90 - 4/96
IVECO DAILY II Bus  1/91 - 2/96
IVECO DAILY II Platform/Chassis  1/89 - 8/98
IVECO Daily I  1/90 - 4/96


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
