• Description
     1232 1430
     HR1044
     Brake Pad Set
     SET

    Front Axle
    Brake System : BNX
    Width : 126 mm
    Width 1 : 147.3 mm
    Height : 76.5 mm
    Height 1 : 59.4 mm
    Thickness : 16.8 mm
    Thickness 1 : 15.8 mm

Brake Pad Set:1232 1430
Model Engine Chassis Type CYL year
CADILLAC ESCALADE  0/98 - 0/06

Application

CADILLAC 60 Special HD Brakes 1993
CADILLAC Commercial Chassis 1991-1993
CADILLAC Concours HD Brakes 1998-1999
CADILLAC DeVille HD Brakes 1990-1993
CADILLAC DeVille Rear Drum 1997-1999
CADILLAC Escalade 1999-2000
CADILLAC Fleetwood HD Brakes 1990-1992
CHEVROLET TRUCK Astro AWD 1990-2002
CHEVROLET TRUCK Blazer 1992-1994
CHEVROLET TRUCK C1500 1992-1999
CHEVROLET TRUCK C1500 HD Chassis 1988-1991
CHEVROLET TRUCK C1500 Suburban 1992-1999
CHEVROLET TRUCK C2500 GVW 7,200 Lbs 1988-1999
CHEVROLET TRUCK Express 1500 1996-2002
CHEVROLET TRUCK Express 2500 GVW 7.3K 1996-2002
CHEVROLET TRUCK K1500 1988-1999
CHEVROLET TRUCK K1500 Suburban 1992-1999
CHEVROLET TRUCK K2500 GVW 7,200 Lbs. 1988-1995
CHEVROLET TRUCK Tahoe 1995-2000
DODGE TRUCK Ram 1500 1994-1997
GMC TRUCK C1500 1992-1999
GMC TRUCK C1500 HD Chassis 1988-1991
GMC TRUCK C1500 Suburban 1992-1999
GMC TRUCK C2500 GVW 7,200 Lbs. 1988-1999
GMC TRUCK K1500 1988-1999
GMC TRUCK K1500 Suburban 1992-1999
GMC TRUCK K2500 GVW 7,200 Lbs. 1988-1995
GMC TRUCK Safari AWD 1990-2002
GMC TRUCK Savana 1500 1996-2002
GMC TRUCK Savana 2500 GVW 7,300 Lbs. 1996-2002
GMC TRUCK Yukon 1992-2000
GMC TRUCK Yukon Denali 1999


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
