• Description
     55200-61880
     HR1473
     Brake Pad Set
     SET

    Front Axle
    Brake System : SUM
    Width : 107.3 mm
    Height : 44.6 mm
    Thickness : 14.9 mm

Brake Pad Set:55200-61880
Model Engine Chassis Type CYL year
CHANGAN (CHANA) JIEXUN MPV  4/07 - 2/08
GEO METRO Convertible  1/89 - 2/98
GEO METRO Saloon  1/89 - 2/98
GEO METRO  1/89 - 2/98
LANDWIND (JMC) CV9 (FENGSHANG)  5/06 - 2/08
SUBARU JUSTY II (JMA, MS)  0/95 - 1/03
SUZUKI ALTO (EF)  9/94 - 9/98
SUZUKI ALTO (HA12, HA23)  1/00 - 6/02
SUZUKI CAPPUCINO (EE)  2/92 - 8/95
SUZUKI SWIFT Convertible (SF413)  9/91 - 0/96
SUZUKI SWIFT I (AA)  8/85 - 3/89
SUZUKI SWIFT II (AH,AJ)  1/90 - 5/01
SUZUKI SWIFT II Hatchback (EA,MA)  3/89 - 2/91
SUZUKI (CHANGAN) GAZELLE  1/01 - 2/11

Application

CHEVROLET Metro 2001
CHEVROLET Metro 2 Door 1998-2000
CHEVROLET Metro 4 Door 1998-2000
GEO Metro 1989-1997
SUZUKI Swift 1989-2001


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
