• Description
     04465-30030
     HR1686
     Brake Pad Set
     SET

    Front Axle
    Brake System : AKB
    Width : 117.6 mm
    Height : 58.5 mm
    Thickness : 17 mm

Brake Pad Set:04465-30030

Application

TOYOTA ALTEZZA ALTEZZA GITA 2000 GXE10 2001.05-2005.07
TOYOTA ALTEZZA ALTEZZA GITA 2000 GXE10W 2001.06-2005.07
TOYOTA ALTEZZA ALTEZZA GITA 2000 SXE10 2001.05-2005.07
TOYOTA BREVIS 2500 JCG10 2001.05-2007.05
TOYOTA BREVIS 3000 JCG11 2001.05-2007.05
TOYOTA CROWN 2000 GS171 1999.09-2003.12
TOYOTA CROWN 2000 GS171(W) 2001.08-2003.12
TOYOTA CROWN 2500 JZS171(W) 1999.09-2003.12
TOYOTA CROWN 3000 JZS175(W) 1999.09-2003.12
TOYOTA CROWN 3000 JKS175 2001.08-2003.12
TOYOTA CROWN ATHLETE 2500 GRS180 2003.12-
TOYOTA CROWN ATHLETE 2500 GRS181 2003.12-
TOYOTA CROWN ATHLETE 3000 JZS175 1999.10-
TOYOTA CROWN ESTATE 3000 JZS175W 1999.12-
TOYOTA MARKII BLIT 2000 GX110W 2002.01-2007.05
TOYOTA MARKII BLIT 2500 JZX110W 2002.01-2007.05
TOYOTA MARKII,CHASER,CRESTA 2000 GX110 2000.10-2004.11
TOYOTA MARKII,CHASER,CRESTA 2500 JZX110 2000.10-2004.11
TOYOTA PROGRES 2500 JCG10 2001.04-2007.06
TOYOTA PROGRES 3000 JCG11 2001.04-2007.06
TOYOTA VEROSSA 2000 GX110 2001.06-2004.04
TOYOTA VEROSSA 2500 JZX110W 2001.06-2004.04


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
