Brake Pad Set:MB 277 192--Fujian Huari Automotive Parts Co., Ltd.

Descripción
Ref.:	MB 277 192
Huari No.:	HR1056
Name:	Brake Pad Set
Unit:	SET
Price:
Front Axle Brake System : SUM Width : 127.8 mm Height : 52.67 mm Thickness : 15 mm

Model	Engine			Type	CYL	year
MITSUBISHI COLT II (C1_A)					9/86 - 4/88
COLT II (C1_A) 1.6 Turbo ECi (C13A)	4G32 T/C	1597	125	Hatchback	4	2/84 - 4/88
COLT II (C1_A) 1.6 Turbo ECi (C13A)	G32BT	1597	105	Hatchback	4	7/86 - 4/88
COLT II (C1_A) 1.8 GL Diesel (C14A)	4D65	1796	58	Hatchback	4	2/84 - 9/86
COLT II (C1_A) 1.8 GL Diesel (C14A)	4D65	1796	60	Hatchback	4	9/86 - 4/88
MITSUBISHI COLT III (C5_A)					4/88 - 5/90
COLT III (C5_A) 1.3 (C51A)	4G13	1299	70	Hatchback	4	4/88 - 5/92
COLT III (C5_A) 1.6 GTi 16V (C53A)	4G61	1596	124	Hatchback	4	4/88 - 5/90
MITSUBISHI CORDIA (A21_A, AB, AC)					0/84 - 7/89
CORDIA (A21_A, AB, AC) 1.6 Turbo (A212A)	4G32 T	1597	114	Coupe	4	0/82 - 5/85
CORDIA (A21_A, AB, AC) 1.6 Turbo (A212A)	4G32 T	1597	116	Coupe	4	7/83 - 5/85
CORDIA (A21_A, AB, AC) 1.8 Turbo ECi (A213A)	4G62 T	1795	136	Coupe	4	0/84 - 7/89
MITSUBISHI GALANT III (E1_A)					6/84 - 4/90
GALANT III (E1_A) 1.8 Turbo-D (E14A)	4D65T	1795	82	Saloon	4	6/84 - 4/90
GALANT III (E1_A) 2.0 GLS (E15A)	4G63 (SOHC 8V)	1997	102	Saloon	4	6/84 - 4/90
GALANT III (E1_A) 2.0 GLS (E15A)	G63B	1997	90	Saloon	4	6/86 - 4/90
GALANT III (E1_A) 2.0 Turbo ECi (E15A)	4G63T (SOHC 8V)	1997	150	Saloon	4	6/84 - 4/90
GALANT III (E1_A) 2.4 GLS (E16A)	G64B	2351	112	Saloon	4	7/85 - 4/90
GALANT III (E1_A) 1.6 GLX (E11A)	4G32	1597	75	Saloon	4	6/84 - 4/90
MITSUBISHI GALANT IV (E3_A)					7/89 - 2/92
GALANT IV (E3_A) 1.8 Turbo-D (E34A)	4D65T	1796	75	Hatchback	4	1/88 - 0/92
GALANT IV (E3_A) 2.0 (E39A, E38A, E33A)	4G63 (SOHC 8V)	1997	109	Hatchback	4	4/89 - 0/92
GALANT IV (E3_A) 2.0 4WD (E33A, E38A, E39A)	4G63 (SOHC 8V)	1997	109	Hatchback	4	4/89 - 0/92
GALANT IV (E3_A) 2.0 GTI 16V (E39A, E38A, E33A)	4G63 (SOHC 8V)	1997	144	Hatchback	4	1/88 - 0/92
GALANT IV (E3_A) 2.0 GTI 16V (E39A, E38A, E33A)	4G63 (SOHC 8V)	1997	146	Hatchback	4	1/88 - 0/92
GALANT IV (E3_A) 2.0 GTI 16V 4x4 (E38A, E39A, E33A)	4G63 (SOHC 8V)	1997	144	Hatchback	4	7/89 - 2/92
MITSUBISHI GALANT IV Saloon (E3_A)					6/88 - 0/92
GALANT IV Saloon (E3_A) 1.8 Turbo-D (E34A)	4D65T	1796	75	Saloon	4	2/87 - 0/92
GALANT IV Saloon (E3_A) 2.0 (E39A, E38A, E33A)	4G63 (SOHC 8V)	1997	109	Saloon	4	1/87 - 0/92
GALANT IV Saloon (E3_A) 2.0 4WD (E39A, E38A, E33A)	4G63 (SOHC 8V)	1997	109	Saloon	4	2/88 - 0/92
GALANT IV Saloon (E3_A) 2.0 GTi 16V (E39A, E38A, E33A)	4G63 (SOHC 8V)	1997	145	Saloon	4	1/88 - 0/92
GALANT IV Saloon (E3_A) 2.0 GTi 16V (E39A, E38A, E33A)	4G63 (SOHC 8V)	1997	144	Saloon	4	1/87 - 0/92
GALANT IV Saloon (E3_A) 2.0 GTi 16V 4WD (E39A, E38A, E33A)	4G63 (SOHC 8V)	1997	144	Saloon	4	6/88 - 0/92
MITSUBISHI LANCER III (C1_A, C6_A)					9/86 - 4/88
LANCER III (C1_A, C6_A) 1.8 Diesel (C14AS)	4D65	1796	58	Saloon	4	1/84 - 9/86
LANCER III (C1_A, C6_A) 1.8 Diesel (C14AS)	4D65	1796	60	Saloon	4	9/86 - 4/88
MITSUBISHI LANCER IV (C6_A, C7_A)					1/89 - 5/92
LANCER IV Hatchback (C6_A, C7_A) 1.5 12V (C62A)	4G15 (12V)	1468	90	Hatchback	4	5/89 - 5/92
LANCER IV Hatchback (C6_A, C7_A) 1.6 16V (C76A, C66A)	4G92	1597	113	Hatchback	4	6/92 - 5/94
LANCER IV Hatchback (C6_A, C7_A) 1.8 D (C64A)	4D65	1796	60	Hatchback	4	4/88 - 5/92
LANCER IV Hatchback (C6_A, C7_A) 1.8 4WD (C77A)	4G37	1755	97	Hatchback	4	9/89 - 6/92
LANCER IV Hatchback (C6_A, C7_A) 1.8 GTi 16V (C68A)	4G67	1836	136	Hatchback	4	1/89 - 5/92
MITSUBISHI LANCER IV Saloon (C6_A)					4/88 - 5/92
LANCER IV (C6_A, C7_A) 1.3 (C61A)	G13B	1299	70	Saloon	4	8/88 - 5/92
LANCER IV (C6_A, C7_A) 1.5 12V (C62A)	4G15 (12V)	1468	90	Saloon	4	6/90 - 5/92
LANCER IV (C6_A, C7_A) 1.8 GLX Diesel (C64A)	4D65	1796	60	Saloon	4	4/88 - 5/92
MITSUBISHI SPACE WAGON (D0_V/W)					6/88 - 4/91
SPACE WAGON (D0_V/W) 1.8 4WD (D05V, D05W)	4G37	1755	90	MPV	4	0/87 - 8/88
SPACE WAGON (D0_V/W) 1.8 GLX (D05V, D05W)	4G37	1755	90	MPV	4	1/84 - 2/88
SPACE WAGON (D0_V/W) 1.8 TD (D09V, D09W)	4D65T	1796	75	MPV	4	6/86 - 4/91
SPACE WAGON (D0_V/W) 2.0 4WD (D08W)	4G63 (SOHC 8V)	1997	102	MPV	4	3/85 - 4/91
SPACE WAGON (D0_V/W) 2.0 GLX (D04W)	G63B	1997	84	MPV	4	6/86 - 5/88
SPACE WAGON (D0_V/W) 2.0 GLX 4WD (D08W)	G63B	1997	84	MPV	4	6/86 - 5/88
SPACE WAGON (D0_V/W) 2.0 GLXi (D04W)	4G63 (SOHC 8V)	1997	101	MPV	4	6/88 - 4/91
SPACE WAGON (D0_V/W) 2.0 GLXi 4WD (D08W)	4G63 (SOHC 8V)	1997	101	MPV	4	6/88 - 4/91
MITSUBISHI TREDIA (A21_)					8/84 - 7/86
TREDIA (A21_) 1.6 Turbo (A212)	4G32 T	1597	114	Saloon	4	9/82 - 5/85
TREDIA (A21_) 1.6 Turbo (A212)	4G32 T	1597	116	Saloon	4	9/82 - 7/84
TREDIA (A21_) 1.8 GLS (A215)	4G37	1755	90	Saloon	4	8/84 - 7/86
TREDIA (A21_) 1.8 Turbo	G62B	1796	136	Saloon	4	8/84 - 7/86

Aplicación

DODGE Colt 1985-1987
DODGE Colt Vista 4WD 1990
DODGE Colt Wagon 4WD 1989-1990
EAGLE Summit 1989-1990
MITSUBISHI Cordia 1984-1986
MITSUBISHI Galant 1985-1987
MITSUBISHI Mirage 1.5 Liter Sedan 1989
MITSUBISHI Mirage 1.6 Liter 1985-1986
MITSUBISHI Mirage Sedan 1990
MITSUBISHI Tredia 1984-1986
PLYMOUTH Colt 1990
PLYMOUTH Colt 4WD 1985-1986
PLYMOUTH Colt Station Wagon 4 x 4 1990
PLYMOUTH Colt Turbo 1985-1986
PLYMOUTH Colt Vista 1985-1987
PLYMOUTH Laser 1990

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
