Brake Shoe Set:47420-87501-000--Fujian Huari Automotive Parts Co., Ltd.

Descripción
Ref.:	47420-87501-000
Huari No.:	HRK0029
Name:	Brake Shoe Set
Unit:	SET
Price:
Rear Axle Brake System : SUMITOMO Diameter : 180 mm Width : 38 mm

Model	Engine			Type	CYL	year
DAIHATSU HIJET Box (S8_)					6/86 - 2/89
HIJET Box (S8_) 0.8	CD	843	39	Box	3	6/86 - 2/89
HIJET Box (S8_) 1.0 (S85)	CB	993	45	Box	3	6/86 - 2/89
DAIHATSU HIJET Bus					6/86 - 2/89
HIJET Bus 0.8	CD	843	39	Bus	3	6/86 - 2/89
HIJET Bus 1.0 (S85)	CB	993	45	Bus	3	6/86 - 2/89

Aplicación

DAIHATSU MIDGET II K100P 660 96' 4-01' 7
DAIHATSU ATRAI WAGON S220G 660 CL 99' 6-00' 4
DAIHATSU ATRAI WAGON S230G 660 CL 99' 6-00' 4
DAIHATSU ATRAI WAGON S230G 660 99' 6-00' 4
DAIHATSU ATRAI WAGON S220G 660 99' 6-00' 4
DAIHATSU HIJET S83C 660 90' 4-94' 1
DAIHATSU HIJET S82W 660 F 90' 4-94' 1
DAIHATSU HIJET S82W 660 F 90' 4-94' 1
DAIHATSU HIJET S82V 660 F 90' 4-94' 1
DAIHATSU HIJET S82V 660 F 90' 4-94' 1
DAIHATSU HIJET S82C 660 90' 4-94' 1
DAIHATSU HIJET S83V 660 F 90' 4-94' 1
DAIHATSU HIJET S110P 660 94' 1-99' 1
DAIHATSU HIJET S110W 660 94' 1-99' 1
DAIHATSU HIJET S200V 660 99' 1-00' 5
DAIHATSU HIJET S110C 660 94' 1-99' 1
DAIHATSU HIJET S100W 660 94' 1-99' 1
DAIHATSU HIJET S210V 660 99' 1-00' 5
DAIHATSU HIJET S83V 660 F 90' 4-94' 1
DAIHATSU HIJET S200P 660 99' 1-00' 5
DAIHATSU HIJET S100C 660 94' 1-99' 1
DAIHATSU HIJET S100V 660 94' 1-99' 1
DAIHATSU HIJET S100P 660 94' 1-99' 1
DAIHATSU HIJET S83W 660 F 90' 4-94' 1
DAIHATSU HIJET S83W 660 F 90' 4-94' 1
DAIHATSU HIJET S110V 660 94' 1-99' 1
DAIHATSU HIJET S200C 660 99' 1-00' 5
DAIHATSU HIJET S81V 550 F 86' 5-90' 4
DAIHATSU HIJET S81V 550 F 86' 5-90' 4
DAIHATSU HIJET S80V 550 F 86' 5-90' 4
DAIHATSU HIJET S80V 550 F 86' 5-90' 4
DAIHATSU HIJET S210P 660 99' 1-00' 5
DAIHATSU HIJET S230V 660 CL 99' 1-00' 5
DAIHATSU HIJET S230V 660 99' 1-00' 5
DAIHATSU HIJET S220V 660 CL 99' 1-00' 5
DAIHATSU HIJET S220V 660 99' 1-00' 5
DAIHATSU HIJET S130V 660 94' 1-99' 1
DAIHATSU HIJET S120V 660 94' 1-99' 1
DAIHATSU HIJET S210C 660 99' 1-00' 5
DAIHATSU MOVE L610S 660 ABS 96' 4-

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
