Brake Pad Set:1 433 952--Fujian Huari Automotive Parts Co., Ltd.

Descripción
Ref.:	1 433 952
Huari No.:	HR1320
Name:	Brake Pad Set
Unit:	SET
Price:
Front Axle Brake System : BOS Width : 164.8 mm Height : 66.7 mm Thickness : 18.8 mm

Model	Engine			Type	CYL	year
BYD TANG					6/15 - /
TANG 2.0 TI Hybrid	BYD487ZQA	1999	205	Closed Off-Road Vehicle	4	6/15 - /
FORD TRANSIT Box					4/06 - 8/14
TRANSIT Box 2.3	GZFA	2261	155	Box	4	3/08 - /
TRANSIT Box (FA_ _) 2.3 16V [RWD]	GZFA	2261	145	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	QVFA	2198	110	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	QWFA	2198	130	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.4 TDCi [RWD]	H9FD	2402	140	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 3.2 TDCi [RWD]	SAFA	3199	200	Box	5	9/07 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	SRFA	2198	115	Box	4	0/08 - 8/14
TRANSIT Box (FA_ _) 2.4 TDCi 4x4	H9FB	2402	140	Box	4	1/06 - 8/14
TRANSIT Box (FA_ _) 2.4 TDCi [RWD]	JXFA	2402	115	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	PGFA	2198	140	Box	4	0/07 - 8/14
TRANSIT Box (FA_ _) 2.4 TDCi [RWD]	PHFA	2402	100	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi [RWD]	DRRA	2198	100	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	CYFA	2198	125	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi [RWD]	CYRA	2198	125	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi [RWD]	CVRA	2198	155	Box	4	0/11 - /
TRANSIT Box (FA_ _) 2.2 TDCi 4x4	CYRB	2198	125	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	DRFA	2198	100	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi [RWD]	USRA	2198	136	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.3 16V CNG [RWD]	GZFA	2261	136	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.3 16V LPG [RWD]	GZFA	2261	145	Box	4	4/06 - 8/14
FORD TRANSIT Bus					1/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	P8FA	2198	85	Bus	4	4/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	QVFA	2198	110	Bus	4	4/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	QWFA	2198	130	Bus	4	4/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 3.2 TDCi	SAFA	3199	200	Bus	5	2/08 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	SRFA	2198	115	Bus	4	0/08 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	PGFA	2198	140	Bus	4	0/07 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	CYFA	2198	125	Bus	4	0/11 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi [RWD]	DRRA	2198	100	Bus	4	0/11 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi [RWD]	CYRA	2198	125	Bus	4	0/11 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDCi	H9FD	2402	140	Bus	4	4/06 - /
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi [RWD]	USRA	2198	135	Bus	4	9/11 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDCi	JXFA	2402	115	Bus	4	4/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDCi	PHFA	2402	100	Bus	4	4/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDCi 4x4	H9FB	2402	140	Bus	4	1/06 - 8/14
FORD TRANSIT Flatbed/Chassis					4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.3 16V [RWD]	GZFA	2261	145	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 TDCi [RWD]	JXFA	2402	115	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 TDCi [RWD]	PHFA	2402	100	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	QVFA	2198	110	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	QWFA	2198	130	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 3.2 TDCi [RWD]	SAFA	3199	200	Platform/Chassis	5	9/07 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	SRFA	2198	115	Platform/Chassis	4	0/08 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 TDCi 4x4	H9FB	2402	140	Platform/Chassis	4	1/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	PGFA	2198	140	Platform/Chassis	4	0/07 - 9/11
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	DRFA	2198	100	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi [RWD]	DRRA	2198	100	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	CYFA	2198	125	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi [RWD]	CYRA	2198	125	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi 4x4	CYRB	2198	125	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi [RWD]	CVRA	2198	155	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.3 16V CNG [RWD]	GZFA	2261	136	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.3 16V LPG [RWD]	GZFA	2261	145	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 TDCi [RWD]	H9FD	2402	140	Platform/Chassis	4	4/06 - 8/14
FORD TRANSIT TOURNEO					0/11 - 8/14
TRANSIT TOURNEO 2.2 TDCi	QVFA	2198	110	Bus	4	7/06 - 8/14
TRANSIT TOURNEO 2.2 TDCi	QWFA	2198	131	Bus	4	7/06 - 8/14
TRANSIT TOURNEO 2.2 TDCi	SRFA	2198	115	Bus	4	0/08 - 8/14
TRANSIT TOURNEO 2.2 TDCi	PGFA	2198	140	Bus	4	0/07 - 8/14
TRANSIT TOURNEO 2.2	CYFA	2198	125	Bus	4	0/11 - 8/14
VOLKSWAGEN AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B)					6/16 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 TDI 4motion	CDBA	1968	122	Pickup	4	9/10 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 TDI	CDBA	1968	122	Pickup	4	9/10 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 BiTDI	CDCA	1968	163	Pickup	4	9/10 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 BiTDI 4motion	CDCA	1968	163	Pickup	4	9/10 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 TSI	CFPA	1984	160	Pickup	4	2/10 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 BiTDI 4motion	CNEA	1968	180	Pickup	4	1/11 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 BiTDI	CNEA	1968	180	Pickup	4	1/11 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 TDI	CNFB	1968	140	Pickup	4	7/12 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 TDI 4motion	CNFB	1968	140	Pickup	4	6/12 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 3.0 TDI 4motion	DDXC	2967	224	Pickup	6	6/16 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 3.0 TDI 4motion	DDXB	2967	204	Pickup	6	6/16 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 3.0 TDI	DDXA	2967	163	Pickup	6	6/16 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 3.0 TDI 4motion	DDXA	2967	163	Pickup	6	6/16 - /
VOLKSWAGEN AMAROK Platform/Chassis (S1B)					9/11 - /
AMAROK Platform/Chassis (S1B) 2.0 TDI	CNFB	1968	140	Platform/Chassis	4	9/11 - /
AMAROK Platform/Chassis (S1B) 2.0 TDI	CNEA	1968	180	Platform/Chassis	4	9/11 - /
AMAROK Platform/Chassis (S1B) 2.0 TDI	CDBA	1968	122	Platform/Chassis	4	9/11 - /
AMAROK Platform/Chassis (S1B) 2.0 TDI 4motion	CNEA	1968	180	Platform/Chassis	4	9/11 - /

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
