• Descripción
     04491-87720
     HR1070
     Brake Pad Set
     SET

    Front Axle
    Brake System : SUM
    Width : 102.8 mm
    Width 1 : 108 mm
    Height : 47 mm
    Thickness : 14 mm

Brake Pad Set:04491-87720
Model Engine Chassis Type CYL year
DAIHATSU CHARADE III (G100, G101, G102)  9/88 - 1/92
GEELY FREE CRUISER  4/05 - /
GEELY HAOQING  1/00 - 4/03
GEELY HQ Hatchback  9/05 - /
GEELY HQ SRV  9/05 - /
GEELY HQ Sedan  9/05 - /
GEELY MEIRI  6/99 - 8/04
GEELY MERRIE  7/05 - 2/06
GEELY MR Hatchback  9/05 - /
GEELY MR Sedan  9/05 - /
GEELY ULIO  4/02 - 2/04
HAFEI LOBO / LUBAO  5/03 - 2/08
FAW TIANJIN N3 Hatchback  4/04 - /
FAW TIANJIN N3 Saloon  4/04 - /
FAW TIANJIN TJ7  0/99 - 0/03


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
