     7 736 572 9
     HR1157- 9
     Brake Pad Set
     SET

    Front Axle
    Brake System : ATE
    Width : 149.5 mm
    Height : 52.5 mm
    Thickness : 17.8 mm

Brake Pad Set:7 736 572 9
Model Engine Chassis Type CYL year
FIAT 500 C  2/13 - /
FIAT 500  7/10 - /
FIAT GRANDE PUNTO (199_)  6/06 - /
FIAT PUNTO (199_)  7/13 - /
FIAT PUNTO EVO  0/09 - 2/12
FIAT PUNTO Van (199_)  3/12 - /


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
