Brake Pad Set:04465-23040--Fujian Huari Automotive Parts Co., Ltd.

Описание
Ref.:	04465-23040
Huari No.:	HR1425
Name:	Brake Pad Set
Unit:	SET
Price:
Front Axle Brake System : AKB Width : 140.2 mm Height : 55 mm Thickness : 15.5 mm

Model	Engine			Type	CYL	year
GREAT WALL SING Closed Off-Road Vehicle					6/05 - 5/10
SING Closed Off-Road Vehicle 2.2	491QE	2237	102	Closed Off-Road Vehicle	4	6/05 - 5/10
GREAT WALL SING					8/03 - 5/10
SING 2.2 DN	GA491QE	2237	106	Closed Off-Road Vehicle	4	8/03 - 5/10
TOYOTA HIACE III Box (_H10_)					8/89 - 8/95
HIACE III Box (YH7_, LH6_, LH7_, LH5_, YH5_, YH6_) 2.4 D (LN10, LH11)	2L	2446	78	Box	4	9/89 - 8/95
HIACE III Box (YH7_, LH6_, LH7_, LH5_, YH5_, YH6_) 3.0 D (LH17_, LH16_)	5L	2986	88	Box	4	8/98 - 8/04
HIACE III Box (YH7_, LH6_, LH7_, LH5_, YH5_, YH6_) 2.8 D (LH11, LH10)	3L	2779	83	Box	4	8/89 - 8/00
HIACE III Box (YH7_, LH6_, LH7_, LH5_, YH5_, YH6_) 2.0 (RCH102_, RCH112_)	1RZ	1998	101	Box	4	2/90 - 8/95
HIACE III Box (YH7_, LH6_, LH7_, LH5_, YH5_, YH6_) 2.4 (RZH10)	2RZ-E	2438	120	Box	4	8/89 - 8/95
HIACE III Box (YH7_, LH6_, LH7_, LH5_, YH5_, YH6_) 2.4 D (LH10_, LH11_)	2L	2446	75	Box	4	8/89 - 8/95
TOYOTA HIACE III Wagon (_H10_)					8/87 - 2/04
HIACE III Wagon (_H1_) 3.0 D (LH18_)	5L	2986	88	Bus	4	8/98 - 8/04
HIACE III Wagon (_H1_) 2.8 D (LH12_)	3L	2779	83	Bus	4	8/89 - 8/00
HIACE III Wagon (_H1_) 2.0 (RZH102)	1RZ	1998	101	Bus	4	8/89 - 4/98
HIACE III Wagon (_H1_) 2.4 (RZH103)	2L	2438	120	Bus	4	8/89 - 8/95
HIACE III Wagon (_H1_) 2.4 D (LH102)	2L	2446	75	Bus	4	8/89 - 8/95
HIACE III Wagon (_H1_) 2.4 D (LH5_, LH6_, LH7_, LH10_, LH11_)	2L	2446	78	Bus	4	8/87 - 2/04
TOYOTA HILUX V Pickup (_N_, KZN1_, VZN1_)					0/88 - 8/97
HILUX V Pickup (_N_, KZN1_, VZN1_) 3.0 4WD (RN37_, RN42_, VZN130)	3VZ-E	2959	143	Pickup	6	9/88 - 8/97
HILUX V Pickup (_N_, KZN1_, VZN1_) 2.8 D 4WD (LN10_, LN11_, LN166)	3L	2779	82	Pickup	4	0/88 - 8/97
TOYOTA HILUX VI Pickup (_N1_)					1/02 - 2/05
HILUX VI Pickup (_N1_) 2.4 D (LN150, LN145)	2L	2446	75	Pickup	4	8/97 - 2/06
HILUX VI Pickup (_N1_) 2.5 D-4D (KDN14_, KDN15_, KDN16_, KDN19_)	2KD-FTV	2494	88	Pickup	4	1/01 - 7/05
HILUX VI Pickup (_N1_) 2.4 TD (LN190)	2L-T	2446	90	Pickup	4	8/98 - 1/02
HILUX VI Pickup (_N1_) 3.0 D	5L	2986	91	Pickup	4	1/02 - 2/05

По маркам автомобилей

TOYOTA Pickup 2WD DRW 1989-1993
TOYOTA T100 1 Ton 2WD 1993-1998

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
